SILENCIADOR, REDONDO 4
Ref: M110014577,52 €
Hay existencias
Additional Information
| Peso | 22,4982 kg |
|---|---|
| Style | Style 4 |
| Inlet Diameter | 127.64 MM |
| Outlet Diameter | 127.64 MM |
| Body Diameter Maximum | 281.4 MM |
| Atributos | |
|---|---|
| Flow Direction | Inlet-Outlet |
| Inlet Diameter | 127.64 mm |
| Outlet Diameter | 127.64 mm |
| Body Diameter Maximum | 281.4 mm |
| Body Length | 1168.4 mm |
| Overall Length | 1314.4 mm |
| Rated Flow LR | 40.2 m³/min |
| Rated Flow MR | 56.9 m³/min |
| Rated Flow HR | 69.7 m³/min |
| Back Pressure Low-Range | 25 mm Hg |
| Back Pressure Mid-Range | 51 mm Hg |
| Back Pressure High-Range | 76 mm Hg |
| Attenuation LR | 15 dBA |
| Attenuation HR | 20 dBA |
| Inlet Clock Position | 6:00 |
| Outlet Clock Position | 12:00 |
| Style | Style 4 |
| Price Type | E |
